Tuff™ Clamp On Ultrasonic Transit Time Meter (1"-48" Pipes) 10-36 VDC or 90-245 VAC Accuracy 1% Full Scale

Clamp-On Ultrasonic Flow Meter | Non-Invasive Tuff Meter™ Technology

The Tuff Meter™ clamp-on ultrasonic flow meter offers one of the most versatile, non-invasive liquid measurement solutions available. Install externally on your existing pipe without cutting, welding, or process shutdown.

No Pipe Penetration Required

External mounting eliminates the need for pipe modifications, bypass loops, or process interruption. Canadian CRN (Certificate of Registration Number) requirements do not apply to non-invasive installations, simplifying compliance and reducing installation costs.

High-Accuracy Performance

Delivers exceptional accuracy with 250:1 turndown ratio for reliable measurement across wide flow ranges.

Ideal Applications for Clean to Slightly Contaminated Liquids:

Optimal performance when debris and air bubbles constitute less than 5% of total flow:

• Diesel fuel and petroleum products
• Crude oil measurement
• Process water and cooling water
• Produced water (oil & gas)
• Return water systems
• Vegetable oil and edible oils
• Deionized water (DI water)
• Reverse osmosis (RO) water and ultrapure water

Factory-Configured & Application-Engineered

Each Tuff Meter™ is custom-configured at our facility with a 4-6 week lead time. Our technical team will confirm:

1. Flow media and fluid characteristics
2. Flow rate range and pipe sizing
3. Process pressure and temperature conditions
4. Communication protocol (4-20mA, HART, Modbus, Profibus, etc.)

Contact us for expert application support and competitive pricing on clamp-on ultrasonic flow meters.
